A-Frame Cabin

Structure:

The entire bearer system of the building is made of weldless, special formed Light weight galvanized steel profiles (S350)

Structural study criteria:

Earthquake Terms:  Suitable for 1st degree quake conditions

Climate Terms:  Suitable for 3rd type climate conditions

Snow Load: 80 kg/m²

Wind Speed: 102 km/hour

Chassis Load Capacity: 200 kg/m²

Foundation:

Concrete Foundation will be prepared on-site according to the provided detail by the seller.

Exterior Walls:

Exterior Covering:  11 mm OSB + 10 mm Stone Texture Cement-Boards + Paint.

Structure: 140mm thick Steel Carcass made of 1mm thick Galvanized steel sheet special formed C profiles.

Insulation: 100 mm thick, 40 kg/m3 Rockwool, A1 Class Fire-Retardant, EN 13162.

Interior Covering: Double layer of 12.50mm thick Gypsum-boards + Paint.

Interior Walls:

Both sides Covering: Single layer of 12.50mm thick Gypsum-boards + Paint.

Structure: 90mm thick Steel Carcass made of 1mm thick Galvanized steel sheet special formed C profiles.

Insulation: 80 mm thick, 40 kg/m3 Rockwool, A1 Class Fire-Retardant, EN 13162.

Mid-Floor Slab:

Slab & Stairs Construction: Slab and stairs beams and panels are formed from C profiles cold-formed from 1 mm thick, galvanized steel sheets using rollform machines.

Railing: Metaş 304 Quality Stainless Chrome Stair Railing 100 cm PMK-100.

Mid-floor slab Insulation: 100 mm thick, 40 kg/m3 Rockwool, A1 Class Fire-Retardant, EN 13162.

Slab cover: 18mm OSB.

Ceiling – Roof:

Structure: Roof Trusses, Purlins and ceiling panels are formed from 90-140mm high C profiles cold-formed from 1 mm thick, galvanized steel sheets using rollform machines.

Roof Covering: 11mm OSB + 2mm Moisture Barrier + 2mm BTM Shingle Dragon Sheets.

Roof Insulation: 100 mm thick, 40 kg/m3 Rockwool, A1 Class Fire-Retardant, EN 13162.

Ceiling: One layer of 12.50mm thick Gypsum-boards.

Doors:

Exterior Doors: Anthracite Color, U-PVC windows, Double Functioned (EGE PEN) brand.

Interior Doors: MDF-lam interior doors with wooden frames (220×90).

Windows:

Windows: Anthracite Color, U-PVC windows, Double Functioned (EGE PEN) brand.

Windows Frameworks: 1 mm thick coil coating painted-galvanized steel sheet.

Glass: Double Glazed 4+11+4mm thick (ISICAM) brand.

Electricity System:

Cable: For electric power 2.000W 220Volt sockets 3*2.5 Nym, for lighting lines 2 * 1.5 Nym .

Plumbing System:

Clean Water Pipes: PPRC – FIRAT brand pipes.

Dirty Water Pipes: PVC – FIRAT- GEDİZ brand pipes.

Luminaires & accessories:

Luminaires: Horoz Aura 5W 4200K Led Recessed Spots + Art&Gift Handel Mika Single Ceiling Pendant Lamps.

Electrical Plugs & Switches: VİKO brand (classic type)

Sanitary wares:

Toilet seat: Visam -durabagno Concealed Cistern Drainless Wall Hung WC Set.

Sink and Shower Faucets: Durul Shower Cabin – Koçtaş shower faucet.

Flooring:

Wet areas Floor: 45×45 High quality VitrA Decogrey brand Ceramics.

Rooms Flooring: 8 mm thick underlay + 8mm high quality Laminaed parquet (Stepclick Castle) brand.

Kitchen:

Cabinets: Laminated MDF with high quality accessories.

kitchen sink: Stainless steel.

kitchen mixer: Creavit brand faucet.

Bench: Solid wood panels.
